Features:
1. The use of their own mirror aluminum material, eliminating the polishing process, reduce the process and shorten the process. This material is mirror processing mechanical polishing surface generation, no coating, sandblasting, anode processing, without annealing anode or plating film, can be directly sandblasting, anode processing, sand particle size up to 320 or more rough.
2. Hardness: hardness uniformity, suitable for complex stamping forming, bending, stretching, integer is not easy to break.
3. Surface treatment: pure material, suitable for high requirements of the stability of the anodic oxidation surface treatment, such as chemical polishing, atomization, fog, two-color two anode, sandblasting, chemical sand, dyeing, sealing and other processing.
Application:
The product is suitable for signs, nameplate, computer chassis, household appliances, mobile phone, digital camera, MP3/MP4, notebook computer, video machines, mobile hard disk, CD player, audio panels, calculator, household electronic products requiring high shell or IT. The material is suitable for complex stamping, stretching, bending, drawing, anodizing, etc.. Suitable for high quality, high demand customers.
Packing:
wooden pallet packing, surface with PE film protection, film thickness 50+/-5um, the film quality time is 5 month, aluminum storage sites require dry, ventilated, avoid high temperature and direct sunlight. If the aluminum stored in high temperature or direct sunlight will cause the protection film can not tear off the phenomenon.
1070 H24, H18
Thickness: 0.3--1.0mm
Width: 250mm--1500mm
Surface: Bright finish
| Data sheet | |||
| Total reflection | 86% | Diffuse reflection | ≤12% |
| Specular reflectivity |
80% |
Tension strength | 125N/mm |
| Yield strength |
105N/mm2 |
Rainbow degree | 2 |
| Elongation | 2 | ||
(2) 1085 Aluminium Bright Mirror Sheet Coil
1085 H24, H18
Thickness: 0.3--1.0mm
Width: 250mm--1500mm
Surface: Bright finish
| Aluminium - Technical Data | ||||||||||||
| Product | Type | Total Reflectance |
Specular Reflectance |
Diffuse Reflectance DIN 5036-3 |
Iridescence Scale 1-4 |
Alloy Purity |
Temper (hardness) |
Min Tensile Strength Mpa |
Min Vield Strength Mpa |
Minimum Elongation A5A10 |
||
|
ASTM E 1651 |
DIN 5036-3 |
60° long | 60° trans | |||||||||
| 1085 |
specular standard |
86 | 86 | 80 | 77 | 15 | 1 | Al 99,85 | H18 | 125 | 105 | 2 |
Mirror Aluminum Plate Sheet is widely used for Lighting, Decoration, Architecture, Consumer Electronics.
(1)Lighting Mirror Aluminium Sheet
Nowadays aluminum is a very fashionable metal, widely used in every field. Due to its advantages of corrosion resistance, mechanical strength and excellent plasticity, aluminum is suitable to be used in various mechanical processing. In addition, its excellent light reflection properties and surface processing technology make aluminum applicable to all types of lighting equipment.
Signi Aluminium always focuses on bringing anodized aluminum used in lighting technology field. In the past years, we've been accumulating a lot of experience in lighting.
The main application scopes of products used in lighting include:
• Outdoor lamps
• Lattice lights
• LED lamps and lanterns
• Tri-proof lights
• Tunnel lights
